50-29510
BELDEN CANADA INC - CND$ 29510 Composite Cable 3 Conductors
Description
Multi-Conductor, 16 AWG, 300V, 4 Conductors, 1 Pair, Stranded (26X30) TC - Tinned Copper, XLPE - Cross Linked Polyethylene, Combination, Tape Aluminum Foil-PolYester100% / 2 Braid TC - Tinned Copper 85%, PVC, CSA, FT4, Black
Specifications
| Armoured | No | Shield | Combination |
| AWG Size | 16 | No of Conductors | 4 |
| # of Pairs | 1 | Flame Test Rating | Yes |
| Cable Type | Multi-Conductor | Approximate Diameter (in.) | 0.75 |
| Color | Black | Conductor Material | Stranded (26X30) TC - Tinned Copper |
| CSA | Yes | Name | Belden Multi-Conductor Cable 300V 4 Conductors 1 Pair 16 AWG Black |
| Net Weight KG/ KM | 405 | Net Weight LB/MFT | 272 |
| # of Shields | 2 | Options | Multiple construction and colors available upon request |
| Shield 1 Coverage | 100% | Shield 1 Material | Aluminum Foil Shield |
| Shield 2 Coverage | 85% | Shield 2 Material | Tinned Copper Braid |
| Shield Material | Tape Aluminum Foil-PolYester100% / 2 Braid TC - Tinned Copper 85% | Voltage | 300V |
