50-30800
Texcan Generic 30800 Belden Single Conductor Cable 600V 1 Conductor 2/0 AWG White
50-30800
Texcan Generic 30800 Belden Single Conductor Cable 600V 1 Conductor 2/0 AWG White
Description
Single Conductor, 2/0 AWG, 600V, 1 Conductor, Stranded (504x26) TC - Tinned Copper, BC - Bare Copper, Silicone with Lacquered Glass Braid Covering, Unshielded, Silicone with Lacquered Glass Braid Covering, CSA, White
Specifications
| Armoured | No | Shield | Unshielded |
| AWG Size | 2/0 | No of Conductors | 1 |
| Flame Test Rating | No | Cable Type | Conductor |
| Approximate Diameter (in.) | 0.712 | Color | White |
| Conductor Material | Stranded (504x26) TC - Tinned Copper | CSA | Yes |
| Insulation Material | Silicone with Lacquered Glass Braid Covering | Jacket Material | Silicone with Lacquered Glass Braid Covering |
| Name | Belden Single Conductor Cable 600V 1 Conductor 2/0 AWG White | Net Weight KG/ KM | 857 |
| Net Weight LB/MFT | 576 | Options | Multiple construction and colors available upon request |
| Voltage | 600V |
