50-3109a-010aia
BELDEN CANADA INC - CND$ 123109A 0101000 Overall Beldfoil® Multi-Conductor Cable Aluminum Interlock Armor 22 AWG 4 Pair Conductors Tinned Copper
50-3109a-010aia
BELDEN CANADA INC - CND$ 123109A 0101000 Overall Beldfoil® Multi-Conductor Cable Aluminum Interlock Armor 22 AWG 4 Pair Conductors Tinned Copper
Description
Multi-Pair, 22 AWG, 300V, 4 Pairs, Stranded (7x30) TC - Tinned Copper, FHDPE - Foam High Density Polyethylene, Combination, Tape Aluminum Foil-PolYester100% / 2 Braid TC - Tinned Copper 65%, PVC, AIA, CSA, Black
Specifications
| Armoured | Yes | Shield | Combination |
| AWG Size | 22 | # of Pairs | 4 |
| Flame Test Rating | No | Cable Type | Multi-Pair |
| Approximate Diameter (in.) | 0.454 | Color | Black |
| Conductor Material | Stranded (7x30) TC - Tinned Copper | CSA | Yes |
| Name | Belden Multi-Pair Cable 300V 4 Pairs 22 AWG Black | Net Weight KG/ KM | 391 |
| Net Weight LB/MFT | 263 | # of Shields | 2 |
| Options | Multiple construction and colors available upon request | Shield 1 Coverage | 100% |
| Shield 1 Material | Aluminum Foil Shield | Shield 2 Coverage | 65% |
| Shield 2 Material | Tinned Copper Braid | Shield Material | Tape Aluminum Foil-PolYester100% / 2 Braid TC - Tinned Copper 65% |
| Voltage | 300V |
